Radon Mitigation Fan Size Tool: How to Accurately Estimate Your System’s Airflow Requirements

Radon is a naturally occurring radioactive gas that can accumulate in homes, especially in basements and crawlspaces. High radon levels are a serious health risk, increasing the likelihood of lung cancer. The Radon Mitigation Fan Size Tool is designed to help homeowners, contractors, and building professionals determine the appropriate fan capacity for active radon mitigation systems, ensuring safe indoor air quality and effective radon reduction.

Imagine moving into a beautiful home, only to discover elevated radon levels in the basement. You need a solution that is safe, efficient, and compliant with guidelines. This is where a correctly sized radon mitigation fan is critical. Using the tool, you can quickly estimate the required airflow, understand system requirements, and select a fan that keeps your home safe.

Why Proper Fan Sizing Matters

Active radon mitigation systems rely on sub-slab or sub-membrane depressurization. A fan moves air from beneath the foundation to the outside, preventing radon from entering your living space. Choosing the wrong fan size can result in:

• Insufficient radon reduction – low airflow may fail to remove radon effectively.

• Excessive energy use – oversizing the fan increases electricity costs unnecessarily.

• Premature fan wear – a fan working beyond its design pressure can fail sooner.

The Radon Mitigation Fan Size Tool helps balance these factors by estimating required airflow (CFM) based on foundation area, soil type, suction points, and pipe layout.

How the Radon Mitigation Fan Size Tool Works

The tool simplifies complex calculations into an easy-to-use interface. Here’s how it works:

Inputs

1. Foundation Footprint Area (sq ft) – Total floor area in contact with soil. Larger areas require higher airflow.

2. Soil Permeability – Three categories:

   • High (gravel, coarse sand) – radon moves easily.

   • Medium (loam, sand) – moderate airflow needed.

   • Low (clay, silt) – higher suction required.

3. Number of Suction Points – Single or multiple points; more points reduce required airflow per pipe.

4. Equivalent Pipe Length (ft) – Includes vertical rise and bends. Longer pipes increase resistance, requiring more powerful fans.

Calculation Logic

The tool uses a step-by-step formula based on EPA and international guidelines:

• Soil Factor: High = 80, Medium = 100, Low = 150 (CFM per 1000 sq ft).

• Pressure Factor: Pipe length >80 ft → 1.4, 50–80 ft → 1.2, ≤50 ft → 1.0.

This ensures the selected fan can overcome system resistance while providing adequate radon reduction.

Step-by-Step Examples

Here are three practical scenarios to illustrate the tool’s use:

Example 1: Medium Soil, Single Suction Point

• Foundation: 1,500 sq ft

• Soil: Medium

• Suction Points: 1

• Pipe Length: 50 ft

Calculation:

Takeaway: A medium-sized inline fan efficiently mitigates radon without overworking the system.

Example 2: Low Soil Permeability, Two Suction Points

• Foundation: 2,000 sq ft

• Soil: Low

• Suction Points: 2

• Pipe Length: 60 ft

Calculation:

Takeaway: Splitting suction points in low-permeability soil improves efficiency and ensures compliance with safety standards.

Example 3: High Soil, Multiple Suction Points

• Foundation: 1,200 sq ft

• Soil: High

• Suction Points: 3

• Pipe Length: 90 ft

Calculation:

Takeaway: High-permeability soil allows smaller fans, but pipe length adjustments are essential for system reliability.

Practical Tips for Using the Tool

• Test different pipe layouts and suction points to optimize fan efficiency.

• Always round to the nearest available fan size to ensure compatibility.

• Use radon-specific inline fans rated for continuous operation.

• Verify results with post-installation radon testing (<4 pCi/L).

Related Tools

To enhance your indoor air quality and home safety, explore these resources:

• Air Quality Filter Replacement Calculator – Maintain healthy airflow and reduce allergens.

• Humidity Control Dehumidifier Size Tool – Optimize moisture control to prevent mold.

• Safety & Structural Tools Collection – Explore calculators for accessibility, ventilation, and safety planning.

FAQs

1. Do I need a professional to install the radon fan?
Yes. Professional installation ensures proper suction points, pipe routing, and safety compliance.

2. Can I use a standard attic fan instead of a radon-specific fan?
No. Radon fans are designed for continuous operation and high static pressure; standard fans may fail quickly.

3. How often should I test radon levels after installation?
Test within a week of installation and periodically afterward to ensure levels remain below 4 pCi/L.

Conclusion

The Radon Mitigation Fan Size Tool simplifies the process of choosing the right fan for your system, ensuring effective radon reduction, energy efficiency, and safety. By considering foundation size, soil type, suction points, and pipe layout, you can confidently select the proper fan and reduce radon exposure in your home.

Next Steps: Try the tool with your home’s dimensions, experiment with different layouts, and combine it with other safety tools like humidity control calculators for a healthier indoor environment.
